MDL,SIN,1GD,1:1,SMT,TU, NPB
| APPLICATION-LAN | ETHERNET TRANSFORMER/CHOKE |
| CONSTRUCTION | OPEN FRAME |
| NUMBER OF PORTS | SINGLE |
| PACKAGE | SMT |
| PACKAGE HEIGHT MM | 5.715 |
| PACKAGE LENGTH MM | 17.526 |
| PACKAGE WIDTH MM | 16.002 |
| POE RATING | NON-POE |
| ROHS COMPLIANT | YES-RoHS-6 |
| SPEED | 1000BASE-T |
| TEMPERATURE | 0 TO 70 |
Datasheet Files |
| MANUFACTURER | PART NUMBER |
|---|---|
| Intel | 82540 |
| Intel | 82541 |
| Intel | 82541PI |
| Intel | 82545EM/GM |
| Intel | 82546EB |
| Intel | 82546EI/GI |
| Intel | 82566DM |
| Intel | 82573 |
| Intel | 82576EB |
| Marvell | 88E1111 |
| Marvell | 88E1112 |
| Marvell | 88E1116R |
| Marvell | 88E1118R |
| Marvell | 88E1119R |
| Marvell | 88E1141 |
| Marvell | 88E1510 |
| Marvell | 88E1512 |
| Marvell | 88E1514 |
| Marvell | 88E1518 |
| Qualcomm / Atheros | AR8021 |
| Qualcomm / Atheros | AR8030 |
| Qualcomm / Atheros | AR8031 |
| Qualcomm / Atheros | AR8035 |
| Broadcom | BCM5421xE |
| Broadcom | BCM54612E |
| Broadcom | BCM54614E |
| Broadcom | BCM54618E |
| Broadcom | BCM54619E |
| Texas Instruments | DP83865DVH |
| IC PLUS | IP1001 |
| Microchip / Micrel | KSZ9021xxx |
| Microchip / Micrel | KSZ9031RNXCA/CC |
| Realtek | RTL8110S-32/SBL/SCL |
| Realtek | RTL8111B/F |
| Realtek | RTL8169S-32/BL/CL |
| Realtek | RTL8211BG/BL/CL |
| Realtek | RTL8211BN/CN/DN |
| Realtek | RTL8211E/EG |
| Realtek | RTL8251CL/CN |
| Microsemi / Vitesse | VSC8211 |
| Microsemi / Vitesse | VSC8221XHH |
| Microsemi / Vitesse | VSC8244XHG |
| Microsemi / Vitesse | VSC8538XHJ |
| Microsemi / Vitesse | VSC8558XHJ |
| Microsemi / Vitesse | VSC8658XHJ |
